Tata Intra V30
The trusted Tata Ace range has empowered 24 Lakhs + entrepreneurs while helping individuals achieve their success goals. One of India’s most desired Small Commercial Vehicles.
2565
GWV
35 L
Fuel Tank Capacity
1496 cc DI engine
Engine
Earn More with Better Mileage and Better Pickup
- Big loading area: 2690 mm (8’8”ft) x 1620 mm (5’3”ft) x 400mm(1’3”ft)
- High load carrying capacity: 185R14 Radial Tyres (14” radial tyres).
- 185R14 Radial (Tubeless)
- High performance: Bigger, newer, and more rugged 1496 cm3 (cc)
- Power of 52 KW @ 4000 r/min (70 Hp)
- Torque of 160 Nm @ 1750 - 2750 r/min
- High structural strength, more durability, and lower NVH levels
- Faster pickup: 0-60 kmph in 13.86 seconds
- High load carrying ability: Leaf spring semielliptical heat springs suspension (5 leaves in front, 8 leaves in rear)
- High Ground clearance: 175mm for stability even in poor road conditions
- High Gradability: 41% for a smooth ride on steep ghat roads and flyovers
- Easier handling: Automatically adjustable clutch height
- New-Gen: Wider walk-through cabin with D+1 Seating arrangement
- Electric Power Assisted Steering
- High maneuverability: Smaller turning circle radius of 5250 mm
- High maneuverability: Smaller turning circle radius of 5250 mm
- Gear shift advisor
- Eco Switch
- Higher fuel efficiency: Two driving modes ECO and NORMAL
- Higher Savings: Low maintenance cost and longevity of aggregate life
- High load carrying capability: Rugged and reliable aggregates
- Higher revenue: Long lead applications for higher profits
- Standard warranty of 3 year or 1 lakh km (whichever is earlier)
- 24-hour toll-free helpline no. (1800 209 7979)
- Peace of mind: TATA Samarth & Sampoorna Seva package
Applications
Fruits and Vegetables
Parcel & Courier
Cement
E-Commerce
Municipal application
White Goods
FMCG
Cool drinks
Milk
Construction Material
Engine
| Type | 4 Cylinder : |
| Power | 52 kW @ 4000 r/min |
| Torque | 140 Nm @ 1800-3000 r/mi |
| Gradeability | 37% |
Clutch and Transmission
| Gear Box Type | GBS 65 Synchromesh 5F + 1R |
| Steering | Electric Power Steering |
| Max Speed | 80 km/h |
Brakes
| Brakes | Front - Disc brakes; Rear - Drum brakes |
| Regenerative Brake | |
| Suspension Front | Semi-elliptical leaf springs |
| Suspension Rear | Semi-elliptical leaf springs |
Wheels and Tyres
| Tyres | Tyre Size/Type185 R14 LT |
Vehicle Dimensions (mm)
| Length | 4460 |
| Width | 1692 |
| Height | 1930 |
| Wheelbase | 2450 |
| Front Track | |
| Rear Track | |
| Ground Clearance | 175 |
| Min TCR | 5250 |
Weight (kg)
| GVW | 2565 |
| Payload | 1300 |
Battery
| Battery Chemistry | |
| Battery Energy (kWh) | |
| IP Rating | |
| Certified Range | |
| Slow Charging time | |
| Fast Charging time |
Performance
| Gradability | 37% |
Seating & Warranty
| Seats | D+1 |
| Warranty | 2 Years / 72000 Kms |
| Battery Warranty |
